Multi-Purpose Hole Saws new

ALL HOLE SAWS 550X ARE EQUIPPED WITH AN XTREME FAST ADAPTOR
FAST
F AST
D Z Wood/PlyWood mdf/laminaTeS PlaSTerboard PlaSTicS brick/aeraTed concreTe SofT TileS
mm inches rPm * rPm * rPm * rPm * rPm * rPm * ORDER NO.
19 3/4 1 2300 2300 2300 2100 900 700 10 550-019X
20 25/32 1 2200 2200 2200 2000 900 600 10 550-020X
22 7/8 1 2000 2000 2000 1800 800 600 10 550-022X
25 1 1 1800 1800 1800 1600 700 500 10 550-025X
29 1-1/8 1 1500 1500 1500 1400 600 400 10 550-029X
30 1-3/16 1 1500 1500 1500 1300 600 400 10 550-030X
32 1-1/4 1 1400 1400 1400 1200 500 400 10 550-032X
35 1-3/8 1 1300 1300 1300 1100 500 300 10 550-035X
38 1-1/2 2 1100 1100 1100 1000 400 300 10 550-038X
40 1-9/16 2 1100 1100 1100 1000 400 300 10 550-040X
44 1-3/4 2 1000 1000 1000 900 400 300 10 550-044X
48 1-7/8 2 900 900 900 800 300 200 10 550-048X
51 2 3 800 800 800 800 300 200 10 550-051X
52 2-1/16 3 800 800 800 700 300 200 10 550-052X
54 2-1/8 3 800 800 800 700 300 200 10 550-054X
56 2-3/16 3 800 800 800 700 300 200 10 550-056X
57 2-1/4 3 700 700 700 700 300 200 10 550-057X
60 2-3/8 3 700 700 700 600 300 200 10 550-060X
64 2-1/2 3 700 700 700 600 200 200 10 550-064X
65 2-9/16 3 700 700 700 600 200 200 10 550-065X
68 2-11/16 3 600 600 600 600 200 100 10 550-068X
70 2-3/4 3 600 600 600 500 200 100 10 550-070X
73 2-7/8 3 600 600 600 500 200 100 10 550-073X
76 3 4 500 500 500 500 200 100 10 550-076X
79 3-1/8 4 500 500 500 500 200 100 10 550-079X
80 3-5/32 4 500 500 500 500 200 100 10 550-080X
82 3-15/64 4 500 500 500 500 200 100 10 550-082X
83 3-1/4 4 500 500 500 400 200 100 10 550-083X
89 3-1/2 4 500 500 500 400 200 100 10 550-089X CMT XTREME FAST AND PUSH&LOCK SYSTEMS: NEXT GENERATION HOLE SAW
92 3-5/8 4 400 400 400 400 200 100 10 550-092X
102 4 5 400 400 400 400 100 100 5 550-102X
105 4-1/8 5 400 400 400 300 100 100 5 550-105X
108 4-1/4 5 400 400 400 300 100 100 5 550-108X
111 4-3/8 5 400 400 400 300 100 100 5 550-111X
114 4-1/2 5 300 300 300 300 100 100 5 550-114X
118 4-5/8 6 300 300 300 300 100 100 2 550-118X
127 5 6 300 300 300 300 100 100 2 550-127X
133 5-1/4 6 300 300 300 300 100 100 2 550-133X
152 6 6 200 200 200 200 100 50 2 550-152X
160 6-5/16 7 200 200 200 200 100 50 1 550-160X
168 6-5/8 7 200 200 200 200 100 50 1 550-168X
185 7-5/16 8 200 200 200 200 100 50 1 550-185X
210 8-1/4 8 200 200 200 100 50 50 1 550-210X
* SuggeSTed rPm
550CSX

FLUSH-MOUNT NO FLUSH-MOUNT

Applications:
COUNTERSINK electric flush-mount case installation. Example of commercial electric flush-mount boxes
D Z Wood/PlyWood mdf/laminaTeS PlaSTerboard PlaSTicS brick/aeraTed concreTe SofT TileS ORDER NO.
mm inches rPm * rPm * rPm * rPm * rPm * rPm *
68-73 2-11/16 - 2 3+3 600 600 600 600 200 100 10 550-068CSX
www.cmtorangetools.com 7
